Rear Wheel (model E) Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
HUB, REAR WHEEL
64110-14240
|
$204.54 | ||
|
Unavailable |
|||
|
#2
PANEL, REAR HUB
64200-14860
|
$163.56 | ||
|
Unavailable |
|||
|
#3
BEARING
64352-40401
|
$91.11 | ||
|
Available to order. Add to View Price |
|||
|
#4
SPACER, PANEL
64213-14600
|
$21.95 | ||
|
Unavailable |
|||
|
#5
DUST SEAL, INNER
09285-24001
|
$7.22 | ||
|
Available to order. Add to View Price |
|||
|
#6
COVER, PANEL DUST SEAL
64845-37200
|
$8.57 | ||
|
Unavailable |
|||
|
#7
SHOE SET, BRAKE
54410-14100
Superseded by 64400-40810
|
$35.02 | ||
|
Available to order. Add to View Price |
|||
|
#8
SPRING
64430-14600
|
$4.54 | ||
|
Available to order. Add to View Price |
|||
|
#9
CAM, BRAKE
54441-14101
|
$21.79 | ||
|
Available to order. Add to View Price |
|||
|
#10
SPRING
09448-30007
Superseded by 09448-30007-XC0
|
$6.92 | ||
|
Available to order. Add to View Price |
|||
|
#11
DUST SEAL
09280-12001
|
$2.99 | ||
|
Available to order. Add to View Price |
|||
|
#12
LEVER, BRAKE CAM
64451-14240
Superseded by 64451-14100
|
$49.48 | ||
|
Unavailable |
|||
|
#13
BOLT
01107-06258
Superseded by 01500-06257
|
$2.29 | ||
|
Available to order. Add to View Price |
|||
|
#14
WASHER (12.5X20X1.0)
09160-12011
|
$1.67 | ||
|
Available to order. Add to View Price |
|||
|
#15
AXLE, REAR
64711-14600
|
$43.69 | ||
|
Unavailable |
|||
|
#16
SPACER, AXLE LH
64751-14240
|
$9.52 | ||
|
Unavailable |
|||
|
#17
THRUST WASHER (T:1.0)
08211-17361
|
$2.84 | ||
|
Available to order. Add to View Price |
|||
|
#18
NUT, HUB
08314-41168
Superseded by 08314-4016A
|
$4.46 | ||
|
Available to order. Add to View Price |
|||
|
#19
PIN, REAR AXLE
04111-40308
Superseded by 04111-4030A
|
$1.60 | ||
|
Available to order. Add to View Price |
|||
|
#20
SPACER, HUB BEARING
64730-14240
|
$29.84 | ||
|
Unavailable |
|||
|
#21
BEARING
08123-62037
Superseded by 08133-6203B
|
$20.72 | ||
|
Available to order. Add to View Price |
|||
|
#22
BEARING, LH
09267-17001
|
$37.77 | ||
|
Unavailable |
|||
|
#23
OIL SEAL, LH
09284-25003
|
$7.03 | ||
|
Unavailable |
|||
|
#24
SPACER, CHAIN ADJUSTER
64781-40600
|
$19.85 | ||
|
Unavailable |
|||
|
#25
NUT
09140-24007
|
$4.58 | ||
|
Available to order. Add to View Price |
|||
|
#26
SPROCKET, REAR (NT:46)
64511-14220
|
$105.83 | ||
|
Unavailable |
|||
|
#27
SCREW
09120-08009
|
$4.62 | ||
|
Available to order. Add to View Price |
|||
|
#28
NUT
08319-31088
Superseded by 08319-3108A
|
$2.70 | ||
|
Available to order. Add to View Price |
|||
|
#29
WASHER
08322-11088
Superseded by 08322-01087
|
$2.15 | ||
|
Available to order. Add to View Price |
|||
|
#30
ADJUSTER, CHAIN
61410-40600
|
$25.08 | ||
|
Available to order. Add to View Price |
|||
|
#31
BOLT (8X50)
09104-08006
Superseded by 09104-08034
|
$3.58 | ||
|
Available to order. Add to View Price |
|||
|
#32
NUT
08310-12088
Superseded by 08310-00087
|
$2.15 | ||
|
Available to order. Add to View Price |
|||
|
#33
TIRE (140/80-18)
65100-14300
|
$114.69 | ||
|
Unavailable |
|||
|
#34
TUBE, WHEEL INNER
65200-14600
|
$23.79 | ||
|
Unavailable |
|||
|
#35
PROTECTOR, INNER TUBE
65261-33030
|
$5.51 | ||
|
Available to order. Add to View Price |
|||
|
#36
RIM, WHEEL (250x18)
65311-14240
|
$172.26 | ||
|
Unavailable |
|||
|
#37
SPOKE ASSY, REAR
65320-14230
|
$42.99 | ||
|
Unavailable |
|||
|
#38
STOPPER, BEAD
65270-40420
|
$30.10 | ||
|
Unavailable |
|||
|
#39
WASHER
08322-11088
Superseded by 08322-01087
|
$2.15 | ||
|
Unavailable |
|||
|
#40
NUT
08310-12088
Superseded by 08310-00087
|
$2.15 | ||
|
Unavailable |
|||
