Rear Fender Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
COLLAR, AIR CLEANER SETTING
17216-HA7-670
|
$7.29 | ||
|
Available to order. Add to View Price |
|||
|
#2
RUBBER, RR. AIR CLEANER SETTING (NOT AVAILABLE)
17237-HA7-670
|
$6.79 | ||
|
Available to order. Add to View Price |
|||
|
#3
SUSPENSION, SPARK UNIT (SOURCE: VINTAGE PARTS INC.) CUSHION, SPARK UNIT
30405-MN4-000
|
$20.14 | ||
|
Available to order. Add to View Price |
|||
|
#4
MODULE, IGNITION CONTROL (CDI) (OKI) (NOT AVAILABLE)
30410-MN4-602
|
$561.74 | ||
|
Available to order. Add to View Price |
|||
|
#5
LIGHT ASSY., LICENSE (12V 4CP) (NOT AVAILABLE)
33720-MN4-671
|
$106.14 | ||
|
Available to order. Add to View Price |
|||
|
#6
BASE (NOT AVAILABLE)
33721-ME4-671
|
$55.77 | ||
|
Available to order. Add to View Price |
|||
|
#7
LENS, LICENSE LIGHT
33722-MB1-013
|
$22.47 | ||
|
Available to order. Add to View Price |
|||
|
#8
WIRE, LICENSE (NOT AVAILABLE)
33725-MN4-003
|
$11.01 | ||
|
Available to order. Add to View Price |
|||
|
#9
COVER, LICENSE (STANLEY)
33727-ME4-671
|
$29.49 | ||
|
Available to order. Add to View Price |
|||
|
#10
GASKET, LENS
33729-MB1-003
|
$7.45 | ||
|
Available to order. Add to View Price |
|||
|
#11
BULB (12V8W)
34616-568-671
Superseded by 34909-505-003
|
$3.25 | ||
|
Unavailable |
|||
|
#11
BULB (12V8W)
34902-500-003
Superseded by 34909-505-003
|
$3.25 | ||
|
Unavailable |
|||
|
#11
BULB (12V8W)
34908-272-000
Superseded by 34909-505-003
|
$3.25 | ||
|
Unavailable |
|||
|
#11
BULB (12V8W)
34909-505-003
|
$3.25 | ||
|
Unavailable |
|||
|
#11
BULB (12V8W)
34909-505-610
Superseded by 34909-505-003
|
$3.25 | ||
|
Unavailable |
|||
|
#12
BAG, SERVICE BOOK
77251-342-000
Superseded by 77251-GR1-000
|
$5.09 | ||
|
Available to order. Add to View Price |
|||
|
#13
FENDER A, RR. (NOT AVAILABLE)
80101-MN4-000
|
$73.29 | ||
|
Available to order. Add to View Price |
|||
|
#14
FENDER, RR. (NOT AVAILABLE)
80201-MN4-770
|
$128.67 | ||
|
Available to order. Add to View Price |
|||
|
#15
CLAMP, BRAKE HOSE (NOT AVAILABLE)
81200-MN4-000
|
$4.00 | ||
|
Available to order. Add to View Price |
|||
|
#16
GROMMET, SIDE COVER
83551-MA6-000
|
$3.96 | ||
|
Available to order. Add to View Price |
|||
|
#17
BRACKET, NUMBER PLATE (SOURCE: VINTAGE PARTS INC.)
84701-MN4-000
|
$48.18 | ||
|
Available to order. Add to View Price |
|||
|
#18
MARK, TIRE CAUTION (NOT AVAILABLE)
87505-MN4-670
|
$4.31 | ||
|
Available to order. Add to View Price |
|||
|
#19
MARK, DRIVE CHAIN CAUTION (SOURCE: VINTAGE PARTS INC.)
87507-MN4-600
|
$4.57 | ||
|
Available to order. Add to View Price |
|||
|
#20
MARK, ACCESSORIES & LOADING CAUTION (NOT AVAILABLE)
87512-KR3-770
|
$5.64 | ||
|
Available to order. Add to View Price |
|||
|
#21
LABEL, DAMPER ADJUSTING (SOURCE: VINTAGE PARTS INC.)
87519-MN4-300
|
$2.00 | ||
|
Available to order. Add to View Price |
|||
|
#22
BOLT, FLANGE (6MM)
90111-187-000
|
$6.62 | ||
|
Available to order. Add to View Price |
|||
|
#23
PLUG, CONE TYPE
90899-422-610
|
$2.13 | ||
|
Available to order. Add to View Price |
|||
|
#24
NUT, CAP (4MM)
94021-04070-0S
|
$1.04 | ||
|
Available to order. Add to View Price |
|||
|
#25
NUT, FLANGE (6MM)
94050-06000
|
$0.60 | ||
|
Available to order. Add to View Price |
|||
