2007 Yamaha YFZ 450 BILL BALLANCE EDITION FRONT SUSPENSION WHEEL OEM Parts Diagram
Air & Fuel
+
Body, Fairing & Fender
+
Brakes
+
Cooling System
+
Drive & Transmission
+
Electrical
+
Engine
+
Exhaust
+
Foot Control
+
Frame
+
Handlebars & Controls
+
Other
+
Seat
+
Suspension
+
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
FRONT LOWER ARM SUB-
5TG-23507-20-00
Superseded by 5TG-23507-21-00
|
$312.99 | ||
|
Available to order. Add to View Price |
|||
|
#2
BALL JOINT 2
5LP-23579-00-00
|
$60.99 | ||
|
Available to order. Add to View Price |
|||
|
#3
CIRCLIP
99009-30400-00
|
$6.99 | ||
|
Available to order. Add to View Price |
|||
|
#4
BUSH, SOLID
90381-15088-00
|
$19.49 | ||
|
Available to order. Add to View Price |
|||
|
#5
COLLAR
90387-101R3-00
|
$17.99 | ||
|
Available to order. Add to View Price |
|||
|
#6
COVER, THRUST 1
5YT-23517-00-00
Superseded by 1UY-23517-01-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#7
NIPPLE, GREASE
93700-06004-00
Superseded by 93700-06M03-00
|
$7.65 | ||
|
Available to order. Add to View Price |
|||
|
#8
FRONT LOWER ARM SUB-
5TG-23508-20-00
Superseded by 5TG-23508-21-00
|
$248.99 | ||
|
Available to order. Add to View Price |
|||
|
#9
BALL JOINT 2
5LP-23579-00-00
|
$60.99 | ||
|
Unavailable |
|||
|
#10
CIRCLIP
99009-30400-00
|
$6.99 | ||
|
Unavailable |
|||
|
#11
BUSH, SOLID
90381-15088-00
|
$19.49 | ||
|
Unavailable |
|||
|
#12
COLLAR
90387-101R3-00
|
$17.99 | ||
|
Unavailable |
|||
|
#13
COVER, THRUST 1
5YT-23517-00-00
Superseded by 1UY-23517-01-00
|
$6.49 | ||
|
Unavailable |
|||
|
#14
NIPPLE, GREASE
93700-06004-00
Superseded by 93700-06M03-00
|
$7.65 | ||
|
Unavailable |
|||
|
#15
FRONT UPPER ARM SUB
5TG-23505-20-00
Superseded by 5TG-23505-21-00
|
$443.99 | ||
|
Available to order. Add to View Price |
|||
|
#16
FRONT UPPER ARM COMP
5TG-23540-20-00
Superseded by 5TG-23540-22-00
|
$306.99 | ||
|
Available to order. Add to View Price |
|||
|
#17
BUSH, SOLID
90381-15088-00
|
$19.49 | ||
|
Unavailable |
|||
|
#18
COLLAR
90387-100Y6-00
|
$29.99 | ||
|
Available to order. Add to View Price |
|||
|
#19
COVER, THRUST 1
5YT-23517-00-00
Superseded by 1UY-23517-01-00
|
$6.49 | ||
|
Unavailable |
|||
|
#20
NIPPLE, GREASE
93700-06004-00
Superseded by 93700-06M03-00
|
$7.65 | ||
|
Unavailable |
|||
|
#21
STEERING KNUCKLE ASSY (LEFT)
1S3-23501-00-00
Superseded by 1S3-23501-01-00
|
$314.99 | ||
|
Available to order. Add to View Price |
|||
|
#22
WASHER
90209-10229-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#23
NUT, CASTLE
90171-10001-00
|
$5.99 | ||
|
Available to order. Add to View Price |
|||
|
#24
PIN, COTTER
91402-20020-00
Superseded by 91490-20025-00
|
$1.99 | ||
|
Available to order. Add to View Price |
|||
|
#25
FRONT UPPER ARM SUB ASSY RH
5TG-23506-20-00
|
$352.99 | ||
|
Available to order. Add to View Price |
|||
|
#26
FRONT UPPER ARM COMP
5TG-23550-20-00
Superseded by 5TG-23550-22-00
|
$322.99 | ||
|
Available to order. Add to View Price |
|||
|
#27
BUSH, SOLID
90381-15088-00
|
$19.49 | ||
|
Unavailable |
|||
|
#28
COLLAR
90387-100Y6-00
|
$29.99 | ||
|
Unavailable |
|||
|
#29
COVER, THRUST 1
5YT-23517-00-00
Superseded by 1UY-23517-01-00
|
$6.49 | ||
|
Unavailable |
|||
|
#30
NIPPLE, GREASE
93700-06004-00
Superseded by 93700-06M03-00
|
$7.65 | ||
|
Unavailable |
|||
|
#31
STEERING KNUCKLE ASSY (RIGHT)
1S3-23502-00-00
Superseded by 1S3-23502-01-00
|
$318.99 | ||
|
Available to order. Add to View Price |
|||
|
#32
WASHER
90209-10229-00
|
$6.49 | ||
|
Unavailable |
|||
|
#33
NUT, CASTLE
90171-10001-00
|
$5.99 | ||
|
Unavailable |
|||
|
#34
PIN, COTTER
91402-20020-00
Superseded by 91490-20025-00
|
$1.99 | ||
|
Unavailable |
|||
|
#35
BOLT, FLANGE
90105-10135-00
|
$5.49 | ||
|
Available to order. Add to View Price |
|||
|
#36
BOLT, FLANGE
90105-10132-00
Superseded by 90105-10651-00
|
$9.99 | ||
|
Available to order. Add to View Price |
|||
|
#37
WASHER, PLATE
90201-10037-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#38
WASHER, PLATE
90201-10037-00
|
$6.49 | ||
|
Unavailable |
|||
|
#39
NUT, SELF-LOCKING
90185-10012-00
|
$7.99 | ||
|
Available to order. Add to View Price |
|||
|
#40
NUT, SELF-LOCKING
90185-10012-00
|
$7.99 | ||
|
Unavailable |
|||
|
#41
NUT, CASTLE
90171-10001-00
|
$5.99 | ||
|
Unavailable |
|||
|
#42
WASHER
90209-10229-00
|
$6.49 | ||
|
Unavailable |
|||
|
#43
PIN, COTTER
91402-20020-00
Superseded by 91490-20025-00
|
$1.99 | ||
|
Unavailable |
|||
|
#44
SHOCK ABSORBER ASSY
5D3-23350-00-00
|
$689.99 | ||
|
Unavailable |
|||
|
#45
BOLT, FLANGE
90105-10131-00
|
$5.49 | ||
|
Available to order. Add to View Price |
|||
|
#46
NUT, SELF-LOCKING
90185-10012-00
|
$7.99 | ||
|
Unavailable |
|||
|
#47
WASHER, PLATE
90201-10035-00
|
$3.85 | ||
|
Available to order. Add to View Price |
|||
|
#48
HOLDER, BRAKE HOSE 1
5TG-25875-00-00
|
$13.99 | ||
|
Available to order. Add to View Price |
|||
|
#49
HOLDER, BRAKE HOSE 2
5TG-25876-00-00
|
$6.99 | ||
|
Available to order. Add to View Price |
|||
|
#50
BOLT
90109-067F4-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
