Radiator Hose Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
RADIATOR ASSY
1TD-E2460-01-00
Superseded by 1TD-E2460-03-00
|
$332.99 | ||
|
Unavailable |
|||
|
#2
BLOWER ASSY
1TD-E2405-00-00
Superseded by 1TD-E2405-01-00
|
$210.99 | ||
|
Unavailable |
|||
|
#3
PLATE
1PE-E2535-00-00
|
$3.70 | ||
|
Available to order. Add to View Price |
|||
|
#4
BOLT, BLOWER HOLDING
1PE-E2675-00-00
|
$2.80 | ||
|
Available to order. Add to View Price |
|||
|
#5
CAP, RADIATOR
1XD-E2462-00-00
|
$14.49 | ||
|
Available to order. Add to View Price |
|||
|
#6
PIPE 1
5TG-12481-00-00
|
$25.99 | ||
|
Available to order. Add to View Price |
|||
|
#7
BOLT, FLANGE
95022-06012-00
|
$3.10 | ||
|
Available to order. Add to View Price |
|||
|
#8
O-RING
93210-16500-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#9
HOSE 1
1TD-E2576-00-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#10
HOSE 2
1TD-E2577-00-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#11
CLIP
90467-23109-00
Superseded by 90467-23067-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#12
HOSE CLAMP ASSY
90450-32015-00
|
$16.49 | ||
|
Available to order. Add to View Price |
|||
|
#13
GROMMET
90480-15058-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#14
COLLAR
90387-07391-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#15
BOLT, WITH WASHER
90119-06181-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
