Fender Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
FRONT FENDER ASSY
4NL-Y2150-L0-33
|
$756.99 | ||
|
Available to order. Add to View Price |
|||
|
#2
GRAPHIC SET, FRONT FENDER
4NK-21570-90-00
|
$281.99 | ||
|
Unavailable |
|||
|
#3
FLAP 2
4NL-21561-11-00
|
$352.99 | ||
|
Available to order. Add to View Price |
|||
|
#4
NUT, SPRING
90183-06008-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#5
BOLT, BUTTON HEAD
92014-05010-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#6
NUT
95304-05600-00
Superseded by 95380-05600-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#7
FLAP, FRONT FENDER
4NL-21521-10-00
|
$201.99 | ||
|
Available to order. Add to View Price |
|||
|
#8
NUT, SPRING
90183-06008-00
|
$7.49 | ||
|
Unavailable |
|||
|
#9
BOLT, BUTTON HEAD
92014-05010-00
|
$7.49 | ||
|
Unavailable |
|||
|
#10
NUT
95304-05600-00
Superseded by 95380-05600-00
|
$7.49 | ||
|
Unavailable |
|||
|
#11
BOLT, HEXAGON SOCKET HEAD
91314-08025-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#12
MASCOT
4NL-21577-10-00
|
$62.99 | ||
|
Available to order. Add to View Price |
|||
|
#13
SCREW,PAN
90159-06107-00
Superseded by 98517-06012-00
|
$3.55 | ||
|
Available to order. Add to View Price |
|||
|
#14
EMBLEM 3
4YE-2152A-00-00
|
$88.55 | ||
|
Unavailable |
|||
|
#15
EMBLEM
4YE-21578-00-00
|
$86.99 | ||
|
Unavailable |
|||
|
#16
SEAL 1
4NL-21575-10-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#17
REAR FENDER COMP.
4YE-Y2161-50-33
|
$1,120.99 | ||
|
Unavailable |
|||
|
#18
GRAPHIC SET, REAR FENDER
4NK-2165A-90-00
|
$259.99 | ||
|
Unavailable |
|||
|
#19
SEAL 2
4NK-21735-00-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#20
PROTECTOR
3MA-27491-00-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#21
EMBLEM, YAMAHA
99247-00080-00
|
$14.99 | ||
|
Available to order. Add to View Price |
|||
|
#22
FLAP
4NL-21621-10-00
|
$227.99 | ||
|
Available to order. Add to View Price |
|||
|
#23
NUT, SPRING
90183-06008-00
|
$7.49 | ||
|
Unavailable |
|||
|
#24
BOLT, BUTTON HEAD
92014-05010-00
|
$7.49 | ||
|
Unavailable |
|||
|
#25
NUT
95304-05600-00
Superseded by 95380-05600-00
|
$7.49 | ||
|
Unavailable |
|||
|
#26
SEAL 1
4NL-21575-10-00
|
$6.49 | ||
|
Unavailable |
|||
|
#27
DAMPER
4NK-21649-00-00
|
$25.99 | ||
|
Available to order. Add to View Price |
|||
|
#28
GROMMET
90480-15061-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#29
FLAP
4NK-21621-00-33
|
$82.99 | ||
|
Unavailable |
|||
|
#30
NUT, SPRING
90183-06053-00
Superseded by 90183-06069-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#31
BOLT, HEXAGON SOCKET HEAD
90110-06200-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#32
WASHER, PLATE
90202-06170-00
|
$1.90 | ||
|
Available to order. Add to View Price |
|||
|
#33
STAY, 9
4YE-2317W-00-00
|
$287.54 | ||
|
Unavailable |
|||
|
#34
BOLT, BUTTON HEAD
92014-06012-00
|
$3.10 | ||
|
Available to order. Add to View Price |
|||
|
#35
WASHER, PLATE
90201-06043-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#36
BRACKET, REFLECTOR
4NK-21641-00-00
|
$11.49 | ||
|
Unavailable |
|||
|
#37
BOLT, FLANGE (SMALL HEAD)
95024-06010-00
|
$4.35 | ||
|
Available to order. Add to View Price |
|||
|
#38
REAR REFLECTOR ASSY
1FK-85130-00-00
|
$32.99 | ||
|
Available to order. Add to View Price |
|||
|
#39
NUT, FLANGE
95707-05500-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#40
HOSE
90446-07114-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#41
DAMPER 2
5A8-21639-00-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#42
GRIP 1
4YE-F164A-00-00
|
$110.68 | ||
|
Unavailable |
|||
|
#43
GRIP 2
4YE-F164E-00-00
|
$110.68 | ||
|
Unavailable |
|||
|
#44
BOLT, BUTTON HEAD
92014-08014-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#45
STAY 1
4NL-F164F-10-00
|
$185.26 | ||
|
Unavailable |
|||
|
#46
BOLT, FLANGE (SMALL HEAD)
95024-08016-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#47
BACK REST ASSY
4YE-2840F-00-00
Superseded by 4YE-2840F-01-00
|
$164.17 | ||
|
Unavailable |
|||
|
#48
STAY 2
4NL-F164G-00-00
|
$33.84 | ||
|
Unavailable |
|||
|
#49
BOLT, FLANGE (SMALL HEAD)
95024-06010-00
|
$4.35 | ||
|
Unavailable |
|||
|
#50
EMBLEM
5GA-24786-00-00
Superseded by 5GA-24786-01-00
|
$58.99 | ||
|
Available to order. Add to View Price |
|||
|
#51
BRACKET, SEAT LEVER 1
4NK-2475H-00-00
|
$70.99 | ||
|
Available to order. Add to View Price |
|||
|
#52
DAMPER, SEAT
509-24724-00-00
|
$10.49 | ||
|
Available to order. Add to View Price |
|||
|
#53
BOLT, FLANGE
95027-06012-00
|
$3.65 | ||
|
Available to order. Add to View Price |
|||
