Starter Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
KICK AXLE ASSEMBLY
4JW-15660-00-00
|
$248.99 | ||
|
Unavailable |
|||
|
#2
GEAR, KICK
3R4-15641-00-00
|
$106.99 | ||
|
Unavailable |
|||
|
#3
CLIP
90468-26048-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#4
WASHER, PLATE
90201-20358-00
|
$4.85 | ||
|
Unavailable |
|||
|
#5
SPRING, TORSION
90508-30743-00
|
$17.49 | ||
|
Available to order. Add to View Price |
|||
|
#6
GUIDE, SPRING
2VM-15664-00-00
|
$41.99 | ||
|
Available to order. Add to View Price |
|||
|
#7
GEAR, KICK IDLE (23T)
38V-15651-00-00
|
$85.99 | ||
|
Unavailable |
|||
|
#8
WASHER, PLATE
90201-17545-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#9
CIRCLIP
99009-17400-00
|
$4.45 | ||
|
Available to order. Add to View Price |
|||
|
#10
OIL SEAL
93102-20309-00
|
$9.49 | ||
|
Available to order. Add to View Price |
|||
|
#11
KICK CRANK ASSEMBLY
4JW-15620-00-00
|
$230.99 | ||
|
Available to order. Add to View Price |
|||
|
#12
BOSS, KICK CRANK
3SP-15621-02-00
|
$73.99 | ||
|
Available to order. Add to View Price |
|||
|
#13
BALL
93501-04011-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#14
SPRING, COMPRESSION
90501-13720-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#15
O-RING
93210-19216-00
|
$4.95 | ||
|
Available to order. Add to View Price |
|||
|
#16
SCREW, COUNTERSUNK
90152-06010-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#17
BOLT, FLANGE
90105-081A1-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#18
WASHER, PLATE
90201-087A9-00
|
$3.30 | ||
|
Available to order. Add to View Price |
|||
