Fender Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
FRONT FENDER COMP.
1MY-21510-00-JW
Superseded by 1MY-21510-00-33
|
$164.99 | ||
|
Unavailable |
|||
|
#
FENDER, FRONT
1MY-21510-00-97
|
$113.99 | ||
|
Unavailable |
|||
|
#2
GRPHC SET, FRT FNDRFRONT FENDER
3JL-21570-00-00
|
$100.99 | ||
|
Unavailable |
|||
|
#3
BOLT
97021-06012-00
Superseded by 97017-06012-00
|
$3.55 | ||
|
Available to order. Add to View Price |
|||
|
#4
WASHER, SPRING
92995-06100-00
|
$3.20 | ||
|
Available to order. Add to View Price |
|||
|
#5
REAR FENDER COMP.
1RM-21610-01-JW
Superseded by 1RM-21610-01-33
|
$454.99 | ||
|
Unavailable |
|||
|
#
FENDER, REAR
1RM-21610-01-97
|
$229.99 | ||
|
Unavailable |
|||
|
#6
BOLT
97021-06012-00
Superseded by 97017-06012-00
|
$3.55 | ||
|
Unavailable |
|||
|
#7
WASHER, SPRING
92995-06100-00
|
$3.20 | ||
|
Unavailable |
|||
|
#8
BOLT
97022-08012-00
Superseded by 97027-08012-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#9
WASHER, SPRING
92990-08100-00
|
$5.49 | ||
|
Available to order. Add to View Price |
|||
|
#10
STAY 1
1RM-2164F-00-00
|
$245.99 | ||
|
Unavailable |
|||
|
#11
STAY 2
1RM-2164G-00-00
|
$220.99 | ||
|
Unavailable |
|||
|
#12
STAY 3
1RM-2164H-00-00
|
$191.99 | ||
|
Unavailable |
|||
|
#13
STAY 4
1RM-2164J-00-00
|
$191.99 | ||
|
Unavailable |
|||
|
#14
GRIP 1
55R-2164A-02-00
|
$131.99 | ||
|
Unavailable |
|||
|
#15
BOLT, FLANGE
95811-06016-00
Superseded by 95817-06016-00
|
$2.60 | ||
|
Available to order. Add to View Price |
|||
|
#16
BOLT, FLANGE
95811-06016-00
Superseded by 95817-06016-00
|
$2.60 | ||
|
Unavailable |
|||
|
#17
SCREW
90149-08225-00
|
$33.99 | ||
|
Unavailable |
|||
|
#18
BOLT, FLANGE
90105-10217-00
Superseded by 90105-10153-00
|
$5.49 | ||
|
Available to order. Add to View Price |
|||
|
#19
GUARD, MUD
42X-21629-00-00
|
$70.99 | ||
|
Unavailable |
|||
|
#20
SCREW, WITH WASHER
90159-06128-00
|
$2.75 | ||
|
Unavailable |
|||
|
#21
HELMET HANGER ASSY
26H-21308-00-00
Superseded by 26H-21308-01-00
|
$78.99 | ||
|
Available to order. Add to View Price |
|||
|
#22
SCREW
90149-06154-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#23
GRAPHIC SET REAR FREAR FENDER
3JL-2165A-00-00
|
$71.02 | ||
|
Unavailable |
|||
|
#24
EMBLEM, YAMAHA
99236-00020-00
Superseded by 99246-00080-00
|
$18.99 | ||
|
Available to order. Add to View Price |
|||
|
#
EMBLEM, YAMAHA
99235-00020-00
Superseded by 99245-00080-00
|
$10.49 | ||
|
Available to order. Add to View Price |
|||
