Governor Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
PLATE, THRUST 1
4JY-11915-10-00
|
$7.99 | ||
|
Available to order. Add to View Price |
|||
|
#2
SCREW, PAN HEAD
98502-05012-00
Superseded by 98517-05012-00
|
$4.63 | ||
|
Available to order. Add to View Price |
|||
|
#3
PUSH ROD ASSY
1C3-11990-10-00
|
$192.99 | ||
|
Available to order. Add to View Price |
|||
|
#4
COLLAR
90387-085E1-00
|
$6.99 | ||
|
Available to order. Add to View Price |
|||
|
#5
WASHER, PLATE
90201-05021-00
|
$1.92 | ||
|
Available to order. Add to View Price |
|||
|
#6
BOLT, HEXAGON
97002-05012-00
Superseded by 97017-05012-00
|
$7.99 | ||
|
Available to order. Add to View Price |
|||
|
#7
OIL SEAL
93104-08040-00
|
$14.49 | ||
|
Available to order. Add to View Price |
|||
|
#8
FORK, GOVERNOR
3JE-11922-01-00
|
$43.99 | ||
|
Available to order. Add to View Price |
|||
|
#9
BOLT
91312-04006-00
|
$2.91 | ||
|
Available to order. Add to View Price |
|||
|
#10
BEARING
93300-60801-00
Superseded by 93300-60814-00
|
$23.99 | ||
|
Available to order. Add to View Price |
|||
|
#11
SHAFT, GOVERNOR
5X4-11921-02-00
|
$56.99 | ||
|
Available to order. Add to View Price |
|||
|
#12
GEAR, GOVERNOR
5NY-11953-00-00
|
$57.99 | ||
|
Available to order. Add to View Price |
|||
|
#13
SPRING, COMPRESSION
90501-300A0-00
|
$7.99 | ||
|
Available to order. Add to View Price |
|||
|
#14
PLATE
5CU-11952-00-00
|
$17.49 | ||
|
Available to order. Add to View Price |
|||
|
#15
WASHER, PLATE
90201-150U6-00
|
$8.99 | ||
|
Available to order. Add to View Price |
|||
|
#16
COLLAR
90387-152F2-00
|
$14.49 | ||
|
Available to order. Add to View Price |
|||
|
#17
BEARING
93340-21505-00
|
$18.49 | ||
|
Available to order. Add to View Price |
|||
|
#18
RETAINER, WEIGHT
5CU-11912-00-00
|
$60.99 | ||
|
Available to order. Add to View Price |
|||
|
#19
RETAINER
5CU-11911-00-00
|
$119.99 | ||
|
Available to order. Add to View Price |
|||
|
#20
BALL
93507-16020-00
|
$2.34 | ||
|
Available to order. Add to View Price |
|||
|
#21
PIN, DOWEL
93603-14240-00
|
$2.08 | ||
|
Available to order. Add to View Price |
|||
|
#22
COLLAR
90387-107T9-00
Superseded by 90387-103U7-00
|
$7.99 | ||
|
Available to order. Add to View Price |
|||
