Starter Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
KICK SHAFT ASSEMBLY
5CU-15601-00-00
|
$253.99 | ||
|
Unavailable |
|||
|
#2
WASHER, PLATE (T=0.5)
90201-20685-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#3
CIRCLIP, S-TYPE
93410-20038-00
|
$3.55 | ||
|
Available to order. Add to View Price |
|||
|
#4
SPRING, COMPRESSION
90501-16107-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#5
WASHER, PLATE
90201-167P7-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#6
CIRCLIP
99009-16400-00
|
$5.49 | ||
|
Available to order. Add to View Price |
|||
|
#7
GUIDE, SPRING
5CU-15664-00-00
Superseded by 5GR-15664-00-00
|
$26.99 | ||
|
Available to order. Add to View Price |
|||
|
#8
SPRING, TORSION
90508-305B0-00
|
$13.99 | ||
|
Available to order. Add to View Price |
|||
|
#9
WASHER, PLATE
90201-162H4-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#10
GUIDE, RATCHET WHEEL
3Y6-15674-00-00
|
$11.49 | ||
|
Available to order. Add to View Price |
|||
|
#11
WASHER, LOCK
214-15686-00-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#12
BOLT
97027-06016-00
Superseded by 97017-06016-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#13
GEAR, KICK IDLE
5CU-15651-00-00
|
$123.99 | ||
|
Available to order. Add to View Price |
|||
|
#14
WASHER, PLATE (T=1.0)
90201-20276-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#15
CIRCLIP
99009-20400-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#16
OIL SEAL
93102-20484-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#17
KICK CRANK ASSY
4EW-15620-02-00
|
$227.99 | ||
|
Available to order. Add to View Price |
|||
|
#18
BOSS, KICK CRANK
3SP-15621-02-00
|
$73.99 | ||
|
Available to order. Add to View Price |
|||
|
#19
BALL
93501-04011-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#20
SPRING, COMPRESSION
90501-13720-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#21
SCREW, COUNTERSUNK
90152-06010-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#22
O-RING
93210-19216-00
|
$4.95 | ||
|
Available to order. Add to View Price |
|||
|
#23
BOLT, FLANGE
95027-08020-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#24
WASHER, PLATE
90201-087A9-00
|
$3.30 | ||
|
Available to order. Add to View Price |
|||
