Governor Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
LEVER
3JE-11931-00-00
Superseded by 3JE-11931-01-00
|
$26.99 | ||
|
Available to order. Add to View Price |
|||
|
#2
SPRING, TORSION
90508-14783-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#3
PUSH ROD ASSY
3SP-11990-00-00
|
$112.99 | ||
|
Unavailable |
|||
|
#4
WASHER, PLATE
90201-057H5-00
|
$4.05 | ||
|
Available to order. Add to View Price |
|||
|
#5
BOLT
97021-05030-00
Superseded by 97017-05030-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#6
WASHER, SPRING
92990-05100-00
|
$0.30 | ||
|
Available to order. Add to View Price |
|||
|
#7
OIL SEAL
93104-08040-00
|
$13.99 | ||
|
Available to order. Add to View Price |
|||
|
#8
FORK, GOVERNOR
3JE-11922-00-00
Superseded by 3JE-11922-01-00
|
$41.99 | ||
|
Available to order. Add to View Price |
|||
|
#9
BOLT
91316-04006-00
Superseded by 91317-04006-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#10
BEARING (608M4ML01)
93300-60814-00
|
$23.99 | ||
|
Available to order. Add to View Price |
|||
|
#11
BEARING (608M4ML01)
93300-60814-00
|
$23.99 | ||
|
Unavailable |
|||
|
#12
SHAFT, GOVERNOR
5X4-11921-02-00
|
$53.99 | ||
|
Available to order. Add to View Price |
|||
|
#13
GEAR, GOVERNOR
24X-11953-01-00
|
$44.99 | ||
|
Available to order. Add to View Price |
|||
|
#14
SPACER
90560-08213-00
|
$12.99 | ||
|
Available to order. Add to View Price |
|||
|
#15
SPRING, COMPRESSION
90501-244J5-00
|
$3.10 | ||
|
Unavailable |
|||
|
#16
PLATE
5X4-11952-00-00
|
$15.99 | ||
|
Unavailable |
|||
|
#17
WASHER, PLATE
90201-154E9-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#18
COLLAR
90387-152F2-00
|
$13.99 | ||
|
Available to order. Add to View Price |
|||
|
#19
BEARING
93340-21505-00
|
$17.99 | ||
|
Available to order. Add to View Price |
|||
|
#20
RETAINER, WEIGHT
5X5-11912-01-00
|
$63.99 | ||
|
Available to order. Add to View Price |
|||
|
#21
RETAINER
4JX-11911-01-00
|
$56.99 | ||
|
Unavailable |
|||
|
#22
BALL
93521-64032-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#23
PIN, DOWEL
93603-14179-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#24
PIN, DOWEL
93604-29184-00
|
$3.05 | ||
|
Available to order. Add to View Price |
|||
