Starter Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
KICK SHAFT ASSY
5NL-15601-00-00
|
$301.99 | ||
|
Available to order. Add to View Price |
|||
|
#2
GEAR, KICK
5NL-15641-00-00
Superseded by 5NL-15641-10-00
|
$106.99 | ||
|
Available to order. Add to View Price |
|||
|
#3
WASHER, PLATE (T=0.5)
90201-20685-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#4
CIRCLIP
93410-20038-00
|
$3.55 | ||
|
Available to order. Add to View Price |
|||
|
#5
WHEEL, RATCHET
4GY-15671-00-00
|
$85.99 | ||
|
Available to order. Add to View Price |
|||
|
#6
SPRING, COMPRESSION
90501-16107-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#7
WASHER, PLATE
90201-167P7-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#8
CIRCLIP
99009-16400-00
|
$5.49 | ||
|
Available to order. Add to View Price |
|||
|
#9
SPRING, TORSION
90508-30743-00
|
$17.49 | ||
|
Available to order. Add to View Price |
|||
|
#10
GUIDE, SPRING
5NL-15664-00-00
|
$12.99 | ||
|
Available to order. Add to View Price |
|||
|
#11
WASHER, PLATE
90201-162H4-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#12
STOPPER
2NX-15668-00-00
|
$23.99 | ||
|
Available to order. Add to View Price |
|||
|
#13
GUIDE, RATCHET WHEEL
214-15674-00-00
Superseded by 2NX-15674-00-00
|
$9.49 | ||
|
Available to order. Add to View Price |
|||
|
#14
WASHER, LOCK
214-15686-00-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#15
BOLT
90101-06001-00
Superseded by 97017-06016-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#16
OIL SEAL
93102-18278-00
|
$11.49 | ||
|
Available to order. Add to View Price |
|||
|
#17
GEAR, KICK IDLE
5NL-15651-00-00
|
$78.99 | ||
|
Available to order. Add to View Price |
|||
|
#18
WASHER, PLATE
90201-177G4-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#19
CIRCLIP
99009-17400-00
|
$4.45 | ||
|
Available to order. Add to View Price |
|||
|
#20
KICK CRANK ASSY
5NL-15620-00-00
Superseded by 5NL-15620-10-00
|
$229.99 | ||
|
Available to order. Add to View Price |
|||
|
#21
BOSS, KICK CRANK
5NL-15621-00-00
Superseded by 5NX-15621-01-00
|
$85.99 | ||
|
Available to order. Add to View Price |
|||
|
#22
SPRING, COMPRESSION
90501-12081-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#23
BALL
93507-32009-00
Superseded by 93507-32031-00
|
$4.45 | ||
|
Available to order. Add to View Price |
|||
|
#24
SCREW, COUNTERSUNK
90152-06010-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#25
O-RING
93210-17570-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#26
WASHER, PLATE
90201-08326-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#27
BOLT
90109-082G0-00
Superseded by 90109-085E2-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
