Governor Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
BOLT, FLANGE
90105-05014-00
|
$2.65 | ||
|
Available to order. Add to View Price |
|||
|
#2
WASHER, PLATE
90201-05021-00
|
$1.92 | ||
|
Available to order. Add to View Price |
|||
|
#3
COLLAR
90387-085E1-00
|
$6.99 | ||
|
Available to order. Add to View Price |
|||
|
#4
PUSH ROD ASSY
BR8-11990-00-00
|
$94.99 | ||
|
Available to order. Add to View Price |
|||
|
#5
FORK, GOVERNOR
3JE-11922-01-00
|
$43.99 | ||
|
Available to order. Add to View Price |
|||
|
#6
BOLT, HEXAGON SOCKET HEAD
91312-04008-00
|
$2.76 | ||
|
Available to order. Add to View Price |
|||
|
#7
SHAFT, GOVERNOR
5X4-11921-02-00
|
$56.99 | ||
|
Available to order. Add to View Price |
|||
|
#8
GEAR, GOVERNOR
BR8-11953-00-00
|
$38.99 | ||
|
Available to order. Add to View Price |
|||
|
#9
SPRING, COMPRESSION
90501-26001-00
|
$3.75 | ||
|
Unavailable |
|||
|
#10
PLATE
5CU-11952-00-00
|
$17.49 | ||
|
Available to order. Add to View Price |
|||
|
#11
WASHER, PLATE (T=0.8)
90201-154F5-00
|
$9.99 | ||
|
Available to order. Add to View Price |
|||
|
#12
COLLAR
90387-152F2-00
|
$14.49 | ||
|
Available to order. Add to View Price |
|||
|
#13
BEARING
93340-21505-00
|
$18.49 | ||
|
Available to order. Add to View Price |
|||
|
#14
RETAINER, WEIGHT
5CU-11912-00-00
|
$60.99 | ||
|
Available to order. Add to View Price |
|||
|
#15
RETAINER
5CU-11911-00-00
|
$119.99 | ||
|
Available to order. Add to View Price |
|||
|
#16
BALL
93507-16020-00
|
$2.34 | ||
|
Available to order. Add to View Price |
|||
|
#17
PIN, DOWEL
93603-14240-00
|
$2.08 | ||
|
Available to order. Add to View Price |
|||
|
#18
BEARING
93300-60801-00
Superseded by 93300-60814-00
|
$23.99 | ||
|
Available to order. Add to View Price |
|||
|
#19
BEARING
93300-60801-00
Superseded by 93300-60814-00
|
$23.99 | ||
|
Unavailable |
|||
|
#20
OIL SEAL
93104-08040-00
|
$14.49 | ||
|
Available to order. Add to View Price |
|||
|
#21
COLLAR
90387-080K6-00
|
$1.92 | ||
|
Available to order. Add to View Price |
|||
