2020 Yamaha YZ 65 REAR ARM OEM Parts Diagram
Air & Fuel
+
Body, Fairing & Fender
+
Brakes
+
Cooling System
+
Drive & Transmission
+
Electrical
+
Engine
+
Exhaust
+
Foot Control
+
Frame
+
Handlebars & Controls
+
Other
+
Seat
+
Suspension
+
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
REAR ARM COMP.
BR8-22110-00-00
|
$657.99 | ||
|
Available to order. Add to View Price |
|||
|
#2
PLUG
90338-10150-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#3
SHAFT, PIVOT
BR8-22141-00-00
|
$22.99 | ||
|
Available to order. Add to View Price |
|||
|
#4
NUT, U
95612-12100-00
|
$5.49 | ||
|
Available to order. Add to View Price |
|||
|
#5
WASHER, PLATE
90201-12032-00
|
$5.99 | ||
|
Available to order. Add to View Price |
|||
|
#6
BUSH
90385-17042-00
|
$19.49 | ||
|
Available to order. Add to View Price |
|||
|
#7
BEARING
93317-21746-00
|
$30.99 | ||
|
Available to order. Add to View Price |
|||
|
#8
COLLAR
90387-127J8-00
|
$31.99 | ||
|
Available to order. Add to View Price |
|||
|
#9
COLLAR
90387-127J7-00
|
$26.99 | ||
|
Available to order. Add to View Price |
|||
|
#10
COLLAR
90387-1200U-00
|
$16.49 | ||
|
Available to order. Add to View Price |
|||
|
#11
OIL SEAL
93109-17071-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#12
SEAL, GUARD
BR8-22151-00-00
|
$78.99 | ||
|
Available to order. Add to View Price |
|||
|
#13
SCREW, 1
1C3-22969-20-00
Superseded by 1C3-22969-90-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#14
SUPPORT, CHAIN
BR8-22199-00-00
|
$49.99 | ||
|
Available to order. Add to View Price |
|||
|
#15
COLLAR
90387-06207-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#16
COLLAR
90387-09002-00
|
$4.10 | ||
|
Available to order. Add to View Price |
|||
|
#17
BOLT, FLANGE DEEP RECESS
95E32-08055-00
|
$1.50 | ||
|
Available to order. Add to View Price |
|||
|
#18
NUT, SELF-LOCKING
95602-08200-00
|
$2.99 | ||
|
Available to order. Add to View Price |
|||
|
#19
BOLT, FLANGE DEEP RECESS
95D02-06016-00
|
$0.45 | ||
|
Available to order. Add to View Price |
|||
|
#20
LABEL, TIRE
3RV-21668-A0-00
Superseded by 3RV-21668-A1-00
|
$4.20 | ||
|
Unavailable |
|||
|
#21
SWING ARM PIVOT BEARING KIT
1SN-W002C-00-00
|
$89.99 | ||
|
Available to order. Add to View Price |
|||
