2015 Honda PCX 150 Transmission OEM Parts

Accessory
+
Body, Fairing & Fender
+
Cooling System
+
Dash & Gauges
+
Drive & Transmission
+
Exhaust
+
Foot Control
+
Labels
+
Seat
+

Transmission Diagram

Item MSRP Qty
#1 SLEEVE, RR. BRAKE CAM
11204-KGF-900
$9.60
Available to order.
Add to View Price
#2 TUBE, TRANSMISSION BREATHER
11211-KWN-980
$1.93
Available to order.
Add to View Price
#3 CASE, TRANSMISSION
21200-KWN-710
$275.65
Available to order.
Add to View Price
#4 GASKET, TRANSMISSION CASE
21395-KZR-600
$4.85
Available to order.
Add to View Price
#5 SHAFT, DRIVE (17T)
23411-KZR-601
$24.30
Available to order.
Add to View Price
#6 COUNTERSHAFT (13T)
23421-KZR-600
$14.80
Available to order.
Add to View Price
#7 GEAR, COUNTER (54T)
23422-K36-J00
$37.72
Available to order.
Add to View Price
#8 GEAR, FINAL (44T)
23430-KZR-600
$48.67
Available to order.
Add to View Price
#9 WASHER, SEALING (8MM)
90495-MN5-000
$4.28
Available to order.
Add to View Price
#10 BEARING, RADIAL BALL (6202) (NTN)
91004-KZR-601
$10.47
Available to order.
Add to View Price
#11 BEARING, RADIAL BALL (6201) (NTN)
91006-KZR-601
$8.98
Available to order.
Add to View Price
#12 BEARING, RADIAL BALL (6205UU) (NTN)
91009-KWN-901
$9.11
Available to order.
Add to View Price
#13 OIL SEAL (14X20X3.2)
91201-434-003
$5.11
Available to order.
Add to View Price
#14 OIL SEAL (34X52X7) (ARAI)
91204-K35-J01
$2.98
Available to order.
Add to View Price
#15 PIN, DOWEL (10X12)
94301-10120
$2.47
Available to order.
Add to View Price
#16 CLIP, TUBE (C9)
95002-50000
$1.30
Available to order.
Add to View Price
#17 BOLT, FLANGE (8X45)
95701-08045-00
$1.61
Available to order.
Add to View Price
#18 BOLT, FLANGE (8X55)
95701-08055-00
$2.47
Available to order.
Add to View Price
