Headlight 81-82 Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
RUBBER, AIR CLEANER HOUSING SETTING
17245-107-010
|
$3.30 | ||
|
Available to order. Add to View Price |
|||
|
#2
HEADLIGHT ASSY. (NOT AVAILABLE)
33100-413-671
|
$69.28 | ||
|
Unavailable |
|||
|
#3
RIM, HEADLIGHT
33101-413-671
|
$39.03 | ||
|
Unavailable |
|||
|
#4
SCREW, BEAM ADJUSTING (4MM)
33103-333-000
|
$6.37 | ||
|
Available to order. Add to View Price |
|||
|
#5
SPRING, HEADLIGHT BEAM ADJUSTING
33107-333-000
|
$2.40 | ||
|
Available to order. Add to View Price |
|||
|
#6
NUT, HEADLIGHT BEAM ADJ.
33117-001-023
|
$2.62 | ||
|
Available to order. Add to View Price |
|||
|
#7
WASHER, BEAM ADJUSTING
33119-371-003
|
$3.08 | ||
|
Available to order. Add to View Price |
|||
|
#8
HEADLIGHT UNIT (12V 50/35W)
33120-333-670
|
$91.24 | ||
|
Available to order. Add to View Price |
|||
|
#9
NUT, UNIT HOLDER
33128-200-033
|
$1.93 | ||
|
Available to order. Add to View Price |
|||
|
#10
SUB-WIRE, HORN (NOT AVAILABLE)
38105-115-000
|
$7.44 | ||
|
Available to order. Add to View Price |
|||
|
#11
HORN (NOT AVAILABLE)
38110-465-771
|
$23.11 | ||
|
Available to order. Add to View Price |
|||
|
#12
CLIP, FR. BRAKE CABLE (NOT AVAILABLE)
45467-419-000
|
$4.00 | ||
|
Available to order. Add to View Price |
|||
|
#13
COLLAR, FR. FENDER (WHITE)
61104-428-000
Superseded by 61104-428-010
|
$5.08 | ||
|
Available to order. Add to View Price |
|||
|
#13
COLLAR, RR. FENDER
61105-428-000
|
$4.03 | ||
|
Unavailable |
|||
|
#14
CASE, HEADLIGHT *NH1* (BLACK)
61301-413-000ZA
|
$107.15 | ||
|
Available to order. Add to View Price |
|||
|
#15
COLLAR, HEADLIGHT CASE
61302-413-000
|
$2.94 | ||
|
Available to order. Add to View Price |
|||
|
#16
HOLDER, R. CONNECTOR (NOT AVAILABLE)
61303-413-013
|
$10.23 | ||
|
Available to order. Add to View Price |
|||
|
#17
COLLAR, HEADLIGHT SETTING
61304-292-000
|
$4.17 | ||
|
Available to order. Add to View Price |
|||
|
#18
HOLDER, L. CONNECTOR (NOT AVAILABLE)
61304-413-013
|
$11.88 | ||
|
Available to order. Add to View Price |
|||
|
#19
BRACKET, HEADLIGHT CASE
61311-465-770
Superseded by 61311-465-771
|
$114.04 | ||
|
Available to order. Add to View Price |
|||
|
#19
BRACKET, HEADLIGHT CASE
61311-465-771
|
$114.04 | ||
|
Unavailable |
|||
|
#20
BOOT, HEADLIGHT BRACKET
61312-149-300
|
$2.81 | ||
|
Available to order. Add to View Price |
|||
|
#21
COVER, HORN STAY (NOT AVAILABLE)
61312-399-000
|
$4.65 | ||
|
Available to order. Add to View Price |
|||
|
#22
WASHER (6MM) (NOT AVAILABLE)
90506-634-000
|
$1.58 | ||
|
Available to order. Add to View Price |
|||
|
#23
BOLT-WASHER (6X28)
93401-06028-00
|
$1.13 | ||
|
Available to order. Add to View Price |
|||
|
#23
BOLT-WASHER (6X28)
93481-06028-00
Superseded by 93401-06028-00
|
$1.13 | ||
|
Unavailable |
|||
|
#24
BOLT-WASHER (8X12)
93481-08012-00
|
$0.67 | ||
|
Available to order. Add to View Price |
|||
|
#25
SCREW, PAN (5X8)
93500-05008-0H
|
$0.90 | ||
|
Available to order. Add to View Price |
|||
|
#26
SCREW, PAN (5X16)
93500-05016-0B
|
$1.42 | ||
|
Available to order. Add to View Price |
|||
|
#27
WASHER, SPRING (5MM)
94111-05000
|
$1.13 | ||
|
Available to order. Add to View Price |
|||
|
#28
BOLT, FLANGE (6X12)
95700-06012-00
Superseded by 95701-06012-00
|
$1.64 | ||
|
Available to order. Add to View Price |
|||
|
#28
BOLT, FLANGE (6X12)
95701-06012-00
|
$1.64 | ||
|
Unavailable |
|||
|
#29
BOLT, FLANGE (12X25)
95700-12025-00
Superseded by 95701-12025-00
|
$2.34 | ||
|
Available to order. Add to View Price |
|||
|
#29
BOLT, FLANGE (12X25)
95701-12025-00
|
$2.34 | ||
|
Unavailable |
|||
