Governor Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
PLATE, THRUST 1
4JY-11915-01-00
Superseded by 4JY-11915-10-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#2
SCREW, BIND
98907-05012-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#3
BOLT, FLANGE
90105-05002-00
|
$2.20 | ||
|
Available to order. Add to View Price |
|||
|
#4
WASHER, PLATE
90201-057H5-00
|
$4.05 | ||
|
Available to order. Add to View Price |
|||
|
#5
COLLAR
90387-085E1-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#6
OIL SEAL
93104-08040-00
|
$13.99 | ||
|
Available to order. Add to View Price |
|||
|
#7
PUSH ROD ASSY
5CU-11990-00-00
Superseded by 5CU-11990-10-00
|
$162.99 | ||
|
Available to order. Add to View Price |
|||
|
#8
FORK, GOVERNOR
3JE-11922-01-00
|
$41.99 | ||
|
Available to order. Add to View Price |
|||
|
#9
BOLT
91317-04006-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#10
BEARING
93300-60801-00
Superseded by 93300-60814-00
|
$23.99 | ||
|
Available to order. Add to View Price |
|||
|
#11
BEARING
93300-60801-00
Superseded by 93300-60814-00
|
$23.99 | ||
|
Unavailable |
|||
|
#12
SHAFT, GOVERNOR
5X4-11921-02-00
|
$53.99 | ||
|
Available to order. Add to View Price |
|||
|
#13
GEAR, GOVERNOR
5NY-11953-00-00
|
$54.99 | ||
|
Available to order. Add to View Price |
|||
|
#14
SPRING, COMPRESSION
90501-256L2-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#15
PLATE
5CU-11952-00-00
|
$16.99 | ||
|
Available to order. Add to View Price |
|||
|
#16
WASHER, PLATE
90201-150U6-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#17
COLLAR
90387-152F2-00
|
$13.99 | ||
|
Available to order. Add to View Price |
|||
|
#18
BEARING
93340-21505-00
|
$17.99 | ||
|
Available to order. Add to View Price |
|||
|
#19
RETAINER, WEIGHT
5CU-11912-00-00
|
$57.99 | ||
|
Available to order. Add to View Price |
|||
|
#20
RETAINER
5CU-11911-00-00
|
$114.99 | ||
|
Available to order. Add to View Price |
|||
|
#21
BALL
93507-16020-00
|
$2.25 | ||
|
Available to order. Add to View Price |
|||
|
#22
PIN, DOWEL
93603-14240-00
|
$2.00 | ||
|
Available to order. Add to View Price |
|||
|
#23
PIN, DOWEL
93604-29184-00
|
$3.05 | ||
|
Available to order. Add to View Price |
|||
