Cylinder Head Cover Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
VALVE ASSY REED
12021-1003
|
$72.83 | ||
|
Available to order. Add to View Price |
|||
|
#2
GASKET,CYL HEAD COVER
11009-1065
Superseded by 11060-1416
|
$84.86 | ||
|
Available to order. Add to View Price |
|||
|
#2
GASKET,CYLINDER-HEAD
11009-1237
Superseded by 11060-1537
|
$78.49 | ||
|
Available to order. Add to View Price |
|||
|
#3
COVER,CYLINDER HEAD
14025-1058
|
$172.85 | ||
|
Available to order. Add to View Price |
|||
|
#3
COVER,CYLINDER HEAD
14025-1209
|
$221.29 | ||
|
Available to order. Add to View Price |
|||
|
#4
CAP ASSY,R.H,REED VLV
14075-5001
|
$26.02 | ||
|
Available to order. Add to View Price |
|||
|
#5
CAP ASSY,L.H,REED VLV
14075-5002
|
$27.17 | ||
|
Available to order. Add to View Price |
|||
|
#6
BOLT,HEX HEAD,6X65
92001-1102
|
$3.15 | ||
|
Available to order. Add to View Price |
|||
|
#7
BOLT,FLANGED,6X22
92001-1352
|
$4.17 | ||
|
Available to order. Add to View Price |
|||
|
#8
BOLT,HEX HEAD,6X45
92001-165
|
$5.07 | ||
|
Available to order. Add to View Price |
|||
|
#8
BOLT,HEX HEAD,6X45
92001-165
|
$5.07 | ||
|
Unavailable |
|||
|
#9
BOLT-SOCKET,6X14
120P0614
Superseded by 120CA0614
|
$3.97 | ||
|
Available to order. Add to View Price |
|||
|
#10
HOLDER,TACHOMETER2.3T
13091-1008
|
$4.13 | ||
|
Available to order. Add to View Price |
|||
|
#11
HOLDER,TACHOMETR,3.2T
13091-1009
|
$4.13 | ||
|
Available to order. Add to View Price |
|||
|
#12
GEAR,TACHOMETER,10T
13223-011
|
$91.19 | ||
|
Available to order. Add to View Price |
|||
|
#13
OIL SEAL
92050-075
|
$10.99 | ||
|
Available to order. Add to View Price |
|||
|
#14
RING-O,10MM
92055-1149
|
$6.36 | ||
|
Available to order. Add to View Price |
|||
|
#15
GASKET,TACHOMETER GER
92065-103
|
$3.94 | ||
|
Available to order. Add to View Price |
|||
|
#16
GUIDE,TACHOMETER GEAR
92087-010
|
$23.33 | ||
|
Available to order. Add to View Price |
|||
|
#17
HOLDER SET,TACHOMETER
13091-5001
|
$4.33 | ||
|
Available to order. Add to View Price |
|||
|
#18
COVER,CYLINDER HEAD
14025-1203
|
$133.98 | ||
|
Available to order. Add to View Price |
|||
