Crankcase Cover Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
COVER, CLUTCH
11340-00A00
|
$142.26 | ||
|
Unavailable |
|||
|
#2
.LENS,OIL LEVEL CHECK
11971-33210
|
$20.20 | ||
|
Available to order. Add to View Price |
|||
|
#3
GASKET,CLUTCH C
11482-49201
Superseded by 11482-49202-H17
|
$22.07 | ||
|
Available to order. Add to View Price |
|||
|
#4
PIN
04211-09129
|
$1.75 | ||
|
Available to order. Add to View Price |
|||
|
#5
BOLT (6x30)
01547-06307
|
$2.15 | ||
|
Available to order. Add to View Price |
|||
|
#6
BOLT (6x25)
01547-06257
|
$2.15 | ||
|
Available to order. Add to View Price |
|||
|
#7
GASKET (5.8X13X1.2)
09168-06015
Superseded by 09168-06023
|
$2.15 | ||
|
Available to order. Add to View Price |
|||
|
#8
PLUG
09259-20008
Superseded by 09259-20008-XC0
|
$8.02 | ||
|
Available to order. Add to View Price |
|||
|
#9
O-RING (D:3.1,ID:16.8)
09280-17003
|
$1.75 | ||
|
Available to order. Add to View Price |
|||
|
#10
COVER, CONTACT BREAKER
11381-00A00
|
$56.46 | ||
|
Unavailable |
|||
|
#11
BOLT
01547-05207
|
$2.32 | ||
|
Available to order. Add to View Price |
|||
|
#12
COVER, GENERATOR
11381-00A00
|
$56.46 | ||
|
Unavailable |
|||
|
#13
GASKET,MAGNETO
11483-49200
Superseded by 11483-49210
|
$13.08 | ||
|
Available to order. Add to View Price |
|||
|
#14
PIN (10.4X13X18)
09206-13001
Superseded by 04211-13189
|
$2.32 | ||
|
Available to order. Add to View Price |
|||
|
#15
BOLT (6x45)
01547-06457
|
$2.45 | ||
|
Available to order. Add to View Price |
|||
|
#16
BOLT (6x30)
01547-06307
|
$2.15 | ||
|
Unavailable |
|||
|
#17
BOLT (6x25)
01547-06257
|
$2.15 | ||
|
Unavailable |
|||
|
#18
COVER, ENGINE SPROCKET
11360-00A00
|
$102.71 | ||
|
Unavailable |
|||
|
#19
PIN
04211-09129
|
$1.75 | ||
|
Unavailable |
|||
|
#20
BOLT
01547-06907
Superseded by 01547-0690B
|
$3.42 | ||
|
Available to order. Add to View Price |
|||
|
#21
BOLT (6x85)
01547-06857
|
$3.00 | ||
|
Available to order. Add to View Price |
|||
|
#22
BOLT,CARB
01547-06757
Superseded by 09103-06522
|
$2.68 | ||
|
Available to order. Add to View Price |
|||
|
#23
BOLT (6x60)
01547-06607
|
$2.90 | ||
|
Available to order. Add to View Price |
|||
|
#24
BOLT (6x35)
01547-06357
|
$2.15 | ||
|
Available to order. Add to View Price |
|||
|
#25
COVER, STARTER MOTOR
11382-45410
|
$43.02 | ||
|
Available to order. Add to View Price |
|||
|
#26
BOLT (5x8)
01547-05087
|
$1.57 | ||
|
Available to order. Add to View Price |
|||
