Rear Wheel Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
HUB, REAR
5EL-25311-00-00
|
$272.99 | ||
|
Available to order. Add to View Price |
|||
|
#2
COLLAR
90387-173M5-00
|
$27.99 | ||
|
Available to order. Add to View Price |
|||
|
#3
BEARING
93306-20348-00
|
$37.99 | ||
|
Available to order. Add to View Price |
|||
|
#4
BEARING
93306-30317-00
|
$36.99 | ||
|
Available to order. Add to View Price |
|||
|
#5
OIL SEAL
93102-25044-00
|
$13.99 | ||
|
Available to order. Add to View Price |
|||
|
#6
CLUTCH, HUB
16G-25366-01-00
|
$226.99 | ||
|
Available to order. Add to View Price |
|||
|
#7
DAMPER
5EL-25364-00-00
|
$35.99 | ||
|
Available to order. Add to View Price |
|||
|
#8
O-RING
93210-48530-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#9
O-RING
93210-59531-00
|
$14.99 | ||
|
Available to order. Add to View Price |
|||
|
#10
WASHER
16G-25412-00-00
|
$10.49 | ||
|
Available to order. Add to View Price |
|||
|
#11
NUT
90170-10219-00
Superseded by 90170-10011-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#12
O-RING
93210-57428-00
|
$13.99 | ||
|
Available to order. Add to View Price |
|||
|
#13
SPOKE SET, REAR
5EL-25304-00-00
Superseded by 5KS-25304-00-00
|
$252.99 | ||
|
Available to order. Add to View Price |
|||
|
#14
RIM (MT4.50-15M/C)
94445-15607-00
|
$348.99 | ||
|
Available to order. Add to View Price |
|||
|
#15
BALANCER, WHEEL (15G)
5V4-25398-00-00
Superseded by 3HT-25398-00-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#16
TIRE (170/80-15 M/C 77S K555)
94117-1508W-00
|
$216.99 | ||
|
Available to order. Add to View Price |
|||
|
#
TIRE (170/80-15 M/C 77S G546)
94117-15008-00
|
$188.99 | ||
|
Available to order. Add to View Price |
|||
|
#17
TUBE (170/80-15 M/C PV78)
94217-15298-00
|
$63.99 | ||
|
Available to order. Add to View Price |
|||
|
#
TUBE (170/80-15 M/C PV78)
94217-15299-00
Superseded by 94217-15298-00
|
$63.99 | ||
|
Unavailable |
|||
|
#18
BAND, RIM (4.50-15)
94317-15181-00
|
$4.90 | ||
|
Available to order. Add to View Price |
|||
|
#
BAND, RIM (4.50-15)
94317-15180-00
Superseded by 94317-15181-00
|
$4.90 | ||
|
Unavailable |
|||
|
#19
AXLE, WHEEL
5EL-25381-00-00
Superseded by 5EL-25381-10-00
|
$111.99 | ||
|
Available to order. Add to View Price |
|||
|
#20
WASHER, PLATE
90201-160T2-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#21
NUT, U FLANGE
95604-16200-00
|
$29.99 | ||
|
Available to order. Add to View Price |
|||
|
#22
COLLAR
90387-177Y4-00
|
$33.99 | ||
|
Available to order. Add to View Price |
|||
|
#23
COLLAR, WHEEL
4H7-25377-00-00
|
$12.99 | ||
|
Available to order. Add to View Price |
|||
