Oil Tank Assembly 250 6x6 / W928727 (4922842284005a) Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
CLAMP-HOSE, (LARGE GREEN)
7080307
|
$0.99 | ||
|
Available to order. Add to View Price |
|||
|
#2
Line, Fuel
2870563
Superseded by 8450003-1525
|
$84.99 | ||
|
Available to order. Add to View Price |
|||
|
#3
Filter
2630009
Superseded by 2530009
|
$6.99 | ||
|
Available to order. Add to View Price |
|||
|
#4
FITTING - OUTLET(10)
7052023
|
$24.99 | ||
|
Available to order. Add to View Price |
|||
|
#5
TANK,OIL
5430969
|
|||
|
Unavailable |
|||
|
#6
RIVET(50)
7621457
|
$1.49 | ||
|
Available to order. Add to View Price |
|||
|
#8
GASKET-OIL CAP
5810141
|
$2.99 | ||
|
Available to order. Add to View Price |
|||
|
#9
CAP,OIL TANK
5430779
|
$17.99 | ||
|
Available to order. Add to View Price |
|||
|
#10
Line, Fuel
5521087
Superseded by 8360009-600
|
$49.99 | ||
|
Available to order. Add to View Price |
|||
|
#11
PAD,FUELTANK BRKT. Substituted by 8360026
5810317
|
|||
|
Unavailable |
|||
