Fuel Tank (gsx-r1000al7 E33) (ysf) Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
TANK ASSY, FUEL (BLUE)
44100-17KA0-YSF
|
$1,039.51 | ||
|
Available to order. Add to View Price |
|||
|
#2
.TAPE SET, FUEL TANK
68110-17K00-BDH
|
$49.98 | ||
|
Available to order. Add to View Price |
|||
|
#3
VESSEL,FUEL TANK INNER
44121-17K00
Superseded by 44121-17K01
|
$16.36 | ||
|
Available to order. Add to View Price |
|||
|
#4
CAP SET,FUEL TANK FILLER
44200-17820
|
$218.10 | ||
|
Available to order. Add to View Price |
|||
|
#5
BOLT,FUEL TANK FILLER CAP
44244-11J00
|
$4.70 | ||
|
Available to order. Add to View Price |
|||
|
#6
MOLDING (L:50)
44552-24B10
|
$11.18 | ||
|
Available to order. Add to View Price |
|||
|
#7
NUT
44523-47H00
|
$11.79 | ||
|
Available to order. Add to View Price |
|||
|
#8
BRACKET,FUEL TANK NO.1
44530-17K00
|
$28.83 | ||
|
Available to order. Add to View Price |
|||
|
#9
CUSHION,FUEL TANK SIDE
44541-17K00
|
$5.14 | ||
|
Available to order. Add to View Price |
|||
|
#10
CUSHION,FUEL TANK REAR
44542-17K00
|
$11.34 | ||
|
Available to order. Add to View Price |
|||
|
#11
SPACER,FUEL TANK REAR BRKT
44544-17K00
|
$7.76 | ||
|
Available to order. Add to View Price |
|||
|
#12
BRACKET,FUEL TANK REAR
44551-17K00
|
$62.72 | ||
|
Available to order. Add to View Price |
|||
|
#13
CLIP,NUT
44552-17K00
|
$5.23 | ||
|
Available to order. Add to View Price |
|||
|
#14
SPACER, JOINT
44561-18G00
|
$19.95 | ||
|
Available to order. Add to View Price |
|||
|
#15
BOLT (6X125)
09103-06033
|
$4.60 | ||
|
Available to order. Add to View Price |
|||
|
#16
BOLT (6X18)
09111-06081
|
$4.81 | ||
|
Available to order. Add to View Price |
|||
|
#17
SCREW (6X22)
09139-06191
|
$4.74 | ||
|
Available to order. Add to View Price |
|||
|
#18
NUT (M6)
09159-06086
|
$2.04 | ||
|
Unavailable |
|||
|
#19
WASHER
09160-06012
Superseded by 09160-06054
|
$1.89 | ||
|
Available to order. Add to View Price |
|||
|
#20
CUSHION
09320-08071
|
$3.82 | ||
|
Available to order. Add to View Price |
|||
|
#21
CUSHION,FUEL TANK COVER
44543-17K00
|
$4.12 | ||
|
Available to order. Add to View Price |
|||
|
#22
FASTENER (33X25X2.6)
44572-13G00
|
$13.02 | ||
|
Available to order. Add to View Price |
|||
|
#23
FASTENER, COVER FRONT
44572-44G00
|
$11.98 | ||
|
Available to order. Add to View Price |
|||
|
#24
NUT (M5)
09148-05052
|
$3.96 | ||
|
Available to order. Add to View Price |
|||
|
#25
CLAMP(L:80)
09404-06433
Superseded by 09404-06036
|
$2.02 | ||
|
Available to order. Add to View Price |
|||
|
#26
CLAMP (L:154)
09407-17403
|
$5.78 | ||
|
Available to order. Add to View Price |
|||
|
#27
PROTECTOR,FUEL TANK
44283-17K00
|
$13.09 | ||
|
Available to order. Add to View Price |
|||
|
#28
HOSE,FUEL TANK WATER DRAIN
44423-17K00
Superseded by 44423-17K02
|
$17.30 | ||
|
Unavailable |
|||
|
#29
STAY,FUEL TANK
44574-17K00
|
$35.02 | ||
|
Available to order. Add to View Price |
|||
