Meters ('81 B2) Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#13169
PLATE,PILOT LAMP
13169-1136
|
$5.05 | ||
|
Available to order. Add to View Price |
|||
|
#14025
COVER,METER BRACKET
14025-1101
|
$20.82 | ||
|
Available to order. Add to View Price |
|||
|
#14025A
COVER,METER
25012-025
|
$28.24 | ||
|
Available to order. Add to View Price |
|||
|
#23008
SOCKET,TACHOMETER
23008-1004
|
$33.55 | ||
|
Available to order. Add to View Price |
|||
|
#23008A
SOCKET,SPEEDOMETER
23008-1006
|
$13.96 | ||
|
Available to order. Add to View Price |
|||
|
#23008B
SOCKET,PILOT LAMP
23008-1023
|
$29.61 | ||
|
Available to order. Add to View Price |
|||
|
#23016
LAMP ASSY,PILOT
23016-1013
|
$62.74 | ||
|
Available to order. Add to View Price |
|||
|
#25005
SPEEDOMETER,MPH
25005-1060
|
$423.92 | ||
|
Available to order. Add to View Price |
|||
|
#25008
BRACKET,METER
25008-1013
|
$57.40 | ||
|
Available to order. Add to View Price |
|||
|
#25015
TACHOMETER ASSY
25015-1007
|
$344.40 | ||
|
Available to order. Add to View Price |
|||
|
#25023
COVER,INDICATER LAMP
25023-1011
|
$32.36 | ||
|
Available to order. Add to View Price |
|||
|
#92001
BOLT,HEX HEAD,6X14
92003-204
|
$3.74 | ||
|
Available to order. Add to View Price |
|||
|
#92009
SCREW,TAPPING,4X10
92009-1040
|
$3.57 | ||
|
Available to order. Add to View Price |
|||
|
#92009A
SCREW-CSK-RD-CROS,4X4
222C0445
|
$3.76 | ||
|
Available to order. Add to View Price |
|||
|
#92015
NUT
92015-078
|
$3.42 | ||
|
Available to order. Add to View Price |
|||
|
#92015A
NUT-CAP,5MM
322C0500
Superseded by 322AB0500
|
$3.26 | ||
|
Available to order. Add to View Price |
|||
|
#92022
WASHER,5.2X16X1.2
25009-004
Superseded by 92200-2276
|
$3.53 | ||
|
Available to order. Add to View Price |
|||
|
#92022A
WASHER,6.5X20X1.6
92022-125
Superseded by 92200-0283
|
$1.36 | ||
|
Available to order. Add to View Price |
|||
|
#92022B
WASHER-SPRING,6MM
461K0600
Superseded by 461DB0600
|
$0.64 | ||
|
Available to order. Add to View Price |
|||
|
#92069
BULB 12V 3W
92069-018
|
$4.72 | ||
|
Available to order. Add to View Price |
|||
|
#92075
DAMPER RUBBER-METER
25019-013
|
$5.54 | ||
|
Available to order. Add to View Price |
|||
|
#92075A
SHOCK DAMPER,SPEEDMET
25019-031
|
$17.20 | ||
|
Available to order. Add to View Price |
|||
|
#92075B
DAMPER,8MM
92075-1138
|
$3.53 | ||
|
Available to order. Add to View Price |
|||
|
#92075C
DAMPER RUBBER,METER
92075-248
|
$3.92 | ||
|
Available to order. Add to View Price |
|||
|
#311
NUT-HEX,6MM
311B0600
Superseded by 311AA0600
|
$0.93 | ||
|
Available to order. Add to View Price |
|||
|
#411
WASHER-PLAIN,6MM
411B0600
Superseded by 411AA0600
|
$2.84 | ||
|
Available to order. Add to View Price |
|||
