Air Filter 2 Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
THROTTLE BODY ASSEMBLY
4HH-13750-00-00
|
$857.99 | ||
|
Unavailable |
|||
|
#
THROTTLE BODY ASSEMBLY
4BH-13750-00-00
|
$1,094.99 | ||
|
Unavailable |
|||
|
#2
BODY, THROTTLE 1
4HH-13751-00-00
|
$231.99 | ||
|
Unavailable |
|||
|
#
BODY, THROTTLE 1
4BH-13751-00-00
|
$402.99 | ||
|
Unavailable |
|||
|
#3
BODY, THROTTLE 2
4HH-13752-00-00
|
$231.99 | ||
|
Unavailable |
|||
|
#
BODY, THROTTLE 2
4BH-13752-00-00
|
$402.99 | ||
|
Unavailable |
|||
|
#4
BODY, THROTTLE 3
4HH-13753-00-00
|
$231.99 | ||
|
Unavailable |
|||
|
#
BODY, THROTTLE 3
4BH-13753-00-00
|
$402.99 | ||
|
Unavailable |
|||
|
#5
BODY, THROTTLE 4
4HH-13754-00-00
|
$359.99 | ||
|
Unavailable |
|||
|
#
BODY, THROTTLE 4
4BH-13754-00-00
|
$438.99 | ||
|
Unavailable |
|||
|
#6
PILOT SCREW SET
4BH-14105-00-00
|
$6.55 | ||
|
Unavailable |
|||
|
#7
PIN, FLOAT
4BH-14386-00-00
|
$4.65 | ||
|
Unavailable |
|||
|
#8
CLIP
256-14919-00-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#9
CLIP
820-14137-00-00
|
$4.00 | ||
|
Unavailable |
|||
|
#10
SPRING
4BH-14938-00-00
|
$13.49 | ||
|
Unavailable |
|||
|
#11
SCREW, PAN HEAD
98580-05012-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#12
THROTTLE SCREW SET
4BH-14103-00-00
|
$68.99 | ||
|
Unavailable |
|||
|
#13
SPRING, THROTTLE VALVE
1HX-14131-00-00
|
$8.49 | ||
|
Unavailable |
|||
|
#14
STOP SCREW SET
4BH-1490K-00-00
|
$28.99 | ||
|
Unavailable |
|||
|
#15
WASHER, PLUG SCREW
22F-14117-00-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#16
SCREW, FLAT HEAD
98702-05010-00
|
$0.99 | ||
|
Unavailable |
|||
|
#17
SCREW, PAN HEAD
98580-04008-00
|
$5.49 | ||
|
Available to order. Add to View Price |
|||
|
#18
CASE, STARTER
4BH-14204-00-00
|
$259.99 | ||
|
Unavailable |
|||
|
#19
THROTTLE SENSOR ASSEMBLY
4BH-85885-00-00
|
$226.99 | ||
|
Unavailable |
|||
|
#20
SCREW
4BH-14592-00-00
|
$7.49 | ||
|
Unavailable |
|||
|
#21
WASHER, PLATE
92901-04600-00
Superseded by 92990-04600-00
|
$4.99 | ||
|
Available to order. Add to View Price |
|||
|
#22
PIN, DOWEL
99510-08012-00
Superseded by 91808-12024-00
|
$4.00 | ||
|
Available to order. Add to View Price |
|||
|
#23
PIPE
4BH-13938-00-00
|
$395.99 | ||
|
Unavailable |
|||
|
#24
DAMPER 2
34M-21639-00-00
|
$5.99 | ||
|
Unavailable |
|||
|
#25
BOLT, HEXAGON SOCKET HEAD
91311-06025-00
Superseded by 91314-06025-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#26
FILTER
4BH-13915-00-00
|
$215.99 | ||
|
Unavailable |
|||
|
#27
DAMPER 1
4BH-14425-00-00
|
$26.99 | ||
|
Unavailable |
|||
|
#28
GASKET
4BH-13764-00-00
|
$6.49 | ||
|
Unavailable |
|||
|
#29
INJECTOR ASSEMBLY
4BH-13761-00-00
|
$234.99 | ||
|
Unavailable |
|||
|
#30
RUBBER, INJECTOR
4BH-13766-00-00
|
$4.65 | ||
|
Unavailable |
|||
|
#31
O-RING
4BH-13769-00-00
|
$6.49 | ||
|
Unavailable |
|||
|
#32
REGULATOR, PRESSURE
4BH-13906-00-00
|
$177.99 | ||
|
Unavailable |
|||
|
#33
O-RING
4BH-13769-00-00
|
$6.49 | ||
|
Unavailable |
|||
|
#34
BOLT, HEXAGON SOCKET HEAD
90110-06145-00
Superseded by 91314-06012-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#35
CLIP
90467-13114-00
|
$1.55 | ||
|
Available to order. Add to View Price |
|||
|
#36
PIPE, FUEL 1
4BH-13971-00-00
|
$145.99 | ||
|
Unavailable |
|||
|
#37
PIPE, FUEL 2
4BH-13972-00-00
|
$231.99 | ||
|
Unavailable |
|||
|
#38
PIPE, FUEL 3
4BH-13973-00-00
|
$33.99 | ||
|
Unavailable |
|||
|
#39
BOLT 1
4BH-13573-00-00
|
$19.49 | ||
|
Available to order. Add to View Price |
|||
|
#40
GASKET
90430-12219-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#41
HOSE, VACUUM SENSING 1
4BH-13542-00-00
|
$9.99 | ||
|
Unavailable |
|||
|
#42
HOSE, VACUUM SENSING 2
4BH-13544-00-00
|
$9.99 | ||
|
Unavailable |
|||
|
#43
HOSE, VACUUM SENSING 3
4BH-13532-00-00
|
$5.99 | ||
|
Unavailable |
|||
|
#44
HOSE, VACUUM SENSING 5
4BH-13533-00-00
Superseded by 4BH-13534-00-00
|
$6.99 | ||
|
Unavailable |
|||
|
#45
HOSE, VACUUM SENSING 5
4BH-13534-00-00
|
$6.99 | ||
|
Unavailable |
|||
|
#46
HOSE (L685)
4BH-13535-00-00
Superseded by 90445-090G9-00
|
$30.99 | ||
|
Available to order. Add to View Price |
|||
|
#47
WAY 3
90413-05014-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#48
CLIP
90467-08021-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#49
CLIP
90467-07138-00
|
$0.99 | ||
|
Unavailable |
|||
|
#50
BAND, SWITCH CORD
437-83936-11-00
|
$4.45 | ||
|
Available to order. Add to View Price |
|||
