Rear Wheel Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
WHEEL, CAST REAR
2G2-W2533-21-00
|
$527.99 | ||
|
Unavailable |
|||
|
#2
400 X 18 BS S704
94140-18399-00
|
$54.52 | ||
|
Unavailable |
|||
|
#3
VALVE, RIM
93900-00001-00
Superseded by 93900-00031-00
|
$15.99 | ||
|
Available to order. Add to View Price |
|||
|
#4
SPACER, BEARING
1J7-25317-00-00
|
$7.26 | ||
|
Unavailable |
|||
|
#5
FLANGE, SPACER 1
1J7-25115-01-00
|
$2.17 | ||
|
Unavailable |
|||
|
#6
BEARING (B6204)
93306-20421-00
Superseded by 93306-20461-00
|
$36.99 | ||
|
Available to order. Add to View Price |
|||
|
#7
BEARING
93306-20404-00
Superseded by 93306-20446-00
|
$38.99 | ||
|
Available to order. Add to View Price |
|||
|
#8
COLLAR
90387-20741-00
|
$5.99 | ||
|
Unavailable |
|||
|
#9
OIL SEAL
93102-25044-00
|
$13.99 | ||
|
Available to order. Add to View Price |
|||
|
#10
SEAL, HUB DUST
1J7-25319-01-00
Superseded by 1J7-25319-02-00
|
$25.99 | ||
|
Available to order. Add to View Price |
|||
|
#11
COVER, PLATE
1J7-25327-10-00
|
$5.64 | ||
|
Unavailable |
|||
|
#12
SCREW, WITH WASHER
90159-05018-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#13
BEARING
93306-30417-00
Superseded by 93306-30437-00
|
$61.99 | ||
|
Available to order. Add to View Price |
|||
|
#14
OIL SEAL, SO-TYPE
93104-27026-00
|
$18.49 | ||
|
Available to order. Add to View Price |
|||
|
#15
COLLAR, WHEEL
1J7-25377-00-00
|
$10.76 | ||
|
Unavailable |
|||
|
#16
COVER, HUB DUST
1J7-25367-00-00
|
$5.49 | ||
|
Unavailable |
|||
|
#17
COLLAR
90387-20542-00
|
$2.92 | ||
|
Unavailable |
|||
|
#18
BAR, TENSION
1J7-25371-00-00
|
$18.66 | ||
|
Unavailable |
|||
|
#19
AXLE, WHEEL
1J7-25381-00-00
|
$42.12 | ||
|
Unavailable |
|||
|
#20
PIN,COTTER
91401-40040-00
Superseded by 91490-40045-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#21
WASHER, PLATE
90201-18620-00
|
$4.45 | ||
|
Available to order. Add to View Price |
|||
|
#22
NUT, CASTLE
90171-18043-00
|
$21.99 | ||
|
Unavailable |
|||
|
#23
SPACER, TORQ.STOP (92901-08100)
1J7-25374-00-00
|
$6.49 | ||
|
Unavailable |
|||
|
#24
WASHER, PLATE
90201-085E6-00
|
$9.49 | ||
|
Available to order. Add to View Price |
|||
|
#25
WASHER, SPRING
92990-08100-00
|
$5.49 | ||
|
Available to order. Add to View Price |
|||
|
#26
NUT
95303-08700-00
Superseded by 95380-08700-00
|
$3.25 | ||
|
Available to order. Add to View Price |
|||
|
#27
PIN, COTTER
91490-20020-00
Superseded by 91490-20025-00
|
$1.99 | ||
|
Available to order. Add to View Price |
|||
|
#28
BALANCER, WHEEL (10G)
1A1-25399-00-00
Superseded by 5MT-25398-00-00
|
$16.99 | ||
|
Available to order. Add to View Price |
|||
|
#
BALANCER, WHEEL (10G)
1A1-25398-01-00
Superseded by 5MT-25398-00-00
|
$16.99 | ||
|
Unavailable |
|||
|
#
BALANCER, WHEEL (10G)
2M0-25399-00-00
Superseded by 5MT-25398-00-00
|
$16.99 | ||
|
Unavailable |
|||
