Side Cover Tool Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
BOX
16G-21240-00-00
|
$8.88 | ||
|
Unavailable |
|||
|
#2
BOLT
97011-06025-00
Superseded by 97017-06025-00
|
$4.00 | ||
|
Available to order. Add to View Price |
|||
|
#3
WASHER, SPRING
92995-06100-00
|
$3.20 | ||
|
Available to order. Add to View Price |
|||
|
#4
WASHER, PLATE
90201-06407-00
Superseded by 90201-06747-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#5
COLLAR
90387-060A7-00
Superseded by 90387-06113-00
|
$10.49 | ||
|
Available to order. Add to View Price |
|||
|
#6
GROMMET
90480-16233-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#7
BOLT
97013-08025-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#8
WASHER, SPRING
92990-08100-00
|
$5.49 | ||
|
Available to order. Add to View Price |
|||
|
#9
COLLAR
90387-093H1-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#10
DAMPER
4H7-21746-00-00
|
$6.49 | ||
|
Unavailable |
|||
|
#11
HOOK, BANK
4H7-2175R-00-00
|
$6.49 | ||
|
Unavailable |
|||
|
#12
PLATE, BRIDGE
16G-21243-01-00
|
$7.68 | ||
|
Unavailable |
|||
|
#13
SCREW, PAN HEAD
98580-06020-00
|
$7.49 | ||
|
Available to order. Add to View Price |
|||
|
#14
WASHER, SPRING
92995-06100-00
|
$3.20 | ||
|
Unavailable |
|||
|
#15
WASHER, PLATE
90201-065F3-00
Superseded by 90201-06020-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#16
HOLDER, FUSE
16G-21361-01-00
|
$2.65 | ||
|
Unavailable |
|||
|
#17
BOX
16G-21258-00-00
|
$4.56 | ||
|
Unavailable |
|||
|
#18
SCREW, PAN HEAD
98506-05010-00
Superseded by 98517-05010-00
|
$4.00 | ||
|
Available to order. Add to View Price |
|||
|
#19
WASHER, PLATE
92906-05600-00
Superseded by 92907-05600-00
|
$3.55 | ||
|
Available to order. Add to View Price |
|||
|
#20
WHEEL LOCK ASSEMBLY (4X7-W2171-
4R0-W2171-00-00
Superseded by 4W5-W2171-00-00
|
$106.99 | ||
|
Unavailable |
|||
|
#21
TOOL KIT (16G-28100-10)
1FG-28100-00-00
|
$115.99 | ||
|
Unavailable |
|||
