1980 Kawasaki KE125 CARBURETOR ('82-'83 A9/A10) OEM Parts Diagram
Accessory
+
Air & Fuel
+
Body, Fairing & Fender
+
Brakes
+
Dash & Gauges
+
Drive & Transmission
+
Electrical
+
Engine
+
Exhaust
+
Foot Control
+
Frame
+
Handlebars & Controls
+
Labels
+
Seat
+
Suspension
+
| Item | MSRP | Qty | |
|---|---|---|---|
|
#11009
GASKET,FLOAT CHAMBER
16019-023
|
$18.26 | ||
|
Available to order. Add to View Price |
|||
|
#11009A
GASKET,FLOAT VALVE SEAT
16029-004
|
$3.66 | ||
|
Available to order. Add to View Price |
|||
|
#11009B
GASKET,CABLE GUIDE
16029-007
|
$9.73 | ||
|
Available to order. Add to View Price |
|||
|
#13070
GUIDE,CABLE
16077-010
|
$20.20 | ||
|
Available to order. Add to View Price |
|||
|
#13070A
GUIDE,CABLE
16077-011
|
$20.06 | ||
|
Available to order. Add to View Price |
|||
|
#13169
PLATE,THROTTLE VALVE
13169-1123
|
$6.46 | ||
|
Available to order. Add to View Price |
|||
|
#16001
CARBURETOR ASSY
16001-1243
|
$266.79 | ||
|
Available to order. Add to View Price |
|||
|
#16002
CABLE ADJUSTER
16002-007
|
$10.50 | ||
|
Available to order. Add to View Price |
|||
|
#16004
CAP,MIXING CHAMBER
16004-024
|
$15.28 | ||
|
Available to order. Add to View Price |
|||
|
#16009
JET NEEDLE,5EL24
16009-1066
|
$34.98 | ||
|
Available to order. Add to View Price |
|||
|
#16012
CAP,STARTER PLUNGER
16012-017
|
$21.59 | ||
|
Available to order. Add to View Price |
|||
|
#16016
PLUNGER-ENRICHNER
16016-002
|
$28.80 | ||
|
Available to order. Add to View Price |
|||
|
#16017
NEEDLE JET,AO-0
16017-1062
|
$39.49 | ||
|
Available to order. Add to View Price |
|||
|
#16021
SCREW,THROTTLE STOP
16021-023
|
$21.93 | ||
|
Available to order. Add to View Price |
|||
|
#16025
VALVE,THROTTLE,CA2.5
16025-1018
|
$61.70 | ||
|
Available to order. Add to View Price |
|||
|
#16030
FLOAT VALVE ASSY
16030-024
|
$49.57 | ||
|
Unavailable |
|||
|
#16031
FLOAT
16031-026
|
$62.93 | ||
|
Available to order. Add to View Price |
|||
|
#92001
BOLT,BANJO
92001-146
|
$16.86 | ||
|
Available to order. Add to View Price |
|||
|
#92009
SCREW-PAN-WS-CROS,4X14
223B0414
Superseded by 223AA0414
|
$1.42 | ||
|
Available to order. Add to View Price |
|||
|
#92015
NUT CABLE ADJUST LOCK
16003-004
|
$6.57 | ||
|
Available to order. Add to View Price |
|||
|
#92022
GASKET,MAIN JET COVER
16034-008
|
$6.15 | ||
|
Available to order. Add to View Price |
|||
|
#92022A
WASHER,THROTTLE VALVE
92022-1024
|
$6.16 | ||
|
Available to order. Add to View Price |
|||
|
#92027
RING,JET NEEDLE
92027-1103
|
$6.57 | ||
|
Available to order. Add to View Price |
|||
|
#92033
RING-SNAP
92036-018
|
$3.57 | ||
|
Available to order. Add to View Price |
|||
|
#92037
CIRCLIP
16008-010
|
$8.56 | ||
|
Available to order. Add to View Price |
|||
|
#92037A
CIRCLIP,CABLE GUIDE
16008-011
|
$6.38 | ||
|
Available to order. Add to View Price |
|||
|
#92037B
RING,MAIN JET
16008-012
|
$22.31 | ||
|
Available to order. Add to View Price |
|||
|
#92037C
CLAMP,TUBE
92037-010
|
$3.57 | ||
|
Available to order. Add to View Price |
|||
|
#92043
FLOAT PIN
16032-006
|
$6.52 | ||
|
Available to order. Add to View Price |
|||
|
#92059
TUBE,CARB BREATHER
92059-1011
|
$10.11 | ||
|
Available to order. Add to View Price |
|||
|
#92063
MAIN JET,#A92.5R
92063-1085
|
$11.38 | ||
|
Available to order. Add to View Price |
|||
|
#92064
PILOT JET,#A25
92064-1020
|
$18.12 | ||
|
Available to order. Add to View Price |
|||
|
#92081
SPRING,THROTTLE VALV
16006-024
|
$10.80 | ||
|
Available to order. Add to View Price |
|||
|
#92081A
SPRING-PLUNGER
16013-003
|
$5.79 | ||
|
Available to order. Add to View Price |
|||
|
#92081B
SPRING THR STOP SCREW
16022-005
|
$8.15 | ||
|
Available to order. Add to View Price |
|||
|
#92081C
SPRING,JET NEEDLE
92081-1072
|
$5.21 | ||
|
Available to order. Add to View Price |
|||
|
#220
SCREW-PAN-CROS,3X8
220B0308
Superseded by 220AA0308
|
$0.58 | ||
|
Available to order. Add to View Price |
|||
|
#461
WASHER-SPRING
461F0300
Superseded by 461DA0300
|
$0.46 | ||
|
Available to order. Add to View Price |
|||
